New customers bundling the HT Center Channel with any Towers or BMR Monitors will see a $200 discount in their cart.
Previous owners wanting the discount can request a coupon code which can be entered at checkout.
Any serious home theater installation needs a center channel with broad and even radiation and high power handling and intelligibility. For many situations, a single BMR monitor on its side with the tweeter rotated will be a perfectly satisfactory and economical solution.
But for the most demanding HT applications there is no substitute for a high quality WMTW center that is designed specifically for broad coverage and maximum power handling.
We believe the new HT Center Channel meets that need. It features dual ScanSpeak 5.25" Revelator woofers—the smaller companions of the 8" Revelator used in the BMR tower. In addition to providing a full 6.5 mm of linear one-way excursion (9 mm maximum), the Revelators perform admirably in a sealed cabinet to maximize placement flexibility
The dedicated 4" midrange neo driver is also from ScanSpeak and offers extremely smooth and broad response to over 3 kHz.
The HT's tweeter is a proprietary AMT unit with wider dispersion than typical AMT drivers or 1" dome tweeters.
Finally, a sophisticated 20-element crossover blends the drivers to produce an extremely even response both on axis and far off axis.
Click here for full measurements of the HT Center Channel.
Specifications
| Cabinet | Mirror Ebony, Piano Black, or Natural Walnut |
| Tweeter | Proprietary Air Motion |
| Midrange | ScanSpeak 10f/4424G |
| Woofer | ScanSpeak 5.25" Revelator |
| Frequency Response | 55 Hz - 20kHz (+ 1.5 / - 3db) Anechoic |
| Sensitivity | 88 dB (2.83v/1M) |
| Box Alignment | Sealed |
| Dimensions | 20.5" W X 10 7/8" H X 10 7/8" D |
| Weight | 35 lbs |
| Impedance | 4 Ohms |
| Crossover | Linkwitz-Riley 2nd Order Acoustic at 490 Hz, Linkwitz-Riley 4th Order Acoustic at 3,000 Hz |
